    6MPa Vacuum Pressure Furnace Pressurization Period 15-30 Min 3Pa/H

    Ask Lasest Price
    Brand Name : Ruideer
    Model Number : 200×200×400/300×300×600/350×350×1200/400×400×1200/500×500×1800
    Certification : CE;ISO9001;ISO14001;OHSAS 18001;GB/T29490
    Price : 80000.00—1000000.00(USD)
    Payment Terms : L/C, T/T
    Supply Ability : 8 sets/month
    Delivery Time : 100-120 work days
    • Product Details
    • Company Profile

    6MPa Vacuum Pressure Furnace Pressurization Period 15-30 Min 3Pa/H

    6MPa Vacuum Pressure Furnace Pressurization Period 15-30 Min Vacuum Leakage Rate 3Pa/H


    Description

    This 6MPa vacuum-sintering furnace offers unprecedented value to applications that require sintering furnace technology for cemented carbide and precision ceramic. Quality, efficiency and reliability are just a few of the outstanding attributes that have allowed Ruideer to become the premier supplier of sintering furnaces.


    Features
    1. All these gas pressure sintering furnace are equipped with double control system, double thermocouples and double high pressure sensor to ensure that if one system fails, the other will continue to work reliably.
    2. We use German COAX high-pressure valve, Germany WAKI high-pressure sensor and Germany LEYBOLD or INFICON vacuum gauge for safe and reliable operation, high vacuum level and low vacuum leakage.
    3. Each of these 6MPa vacuum-pressure sintering furnaces is detected by using helium mass spectrometer leak detector.


    Quality Advantages
    Low temperature uniformity test is carried out to ensure the high quality of sinter-HIP furnace. 6 thermocouples are arranged in the furnace.
    (1) Test conditions of vacuum dewaxing or flowing gas dewaxing
    Test temperature: 280°C, 335°C;
    Keep the temperature constant within 180 minutes;
    Tolerance of 6 thermocouple reading: ±5°C.
    (2) Test condition of vacuum sintering
    Test temperature: 600°C, 800°C, 950°C;
    Keep the temperature constant within 180 minutes;
    Tolerance of 6 thermocouple reading: ±5°C.


    Suitable products to sinter:

    Cemented carbide,mental ceramics,ceramics,MIM(Metal injection molding) products, Iron-base alloy, Copper-base alloy, Aluminum etc.


    Functions: Vacuum heating , vacuum dewaxing, heating flowing gas, heating with gas mixture(CO2,CH4,H2), heating pressure gas,Rapid cooling.


    loading Space200*200*400/300*300*600/300*300*900/ 350*350*1200/400*400*1200/500*500*1200/ 500*500*1800/500*500*2700
    Design StandardJB4732-95/GB150/ASME, 20-year service,Double doors horizontal structure, 600 Times
    Max. working Temp1600℃
    Max. working Pressure60bar
    Vacuum Leakage Rate3Pa/h (Average in cold, empty, dry chamber in 24 hours)
    Vacuum pumpSlide-valve Pump, Roots Pump, (Imported Pump or domestic pump according to customer's requirement)
    Wax-collection Rate98%
    Pressurization Period15-30min
    Cooling period (full furnace)3h/4h/ ≤5h/ ≤6h/≤7h/≤7h/≤8h/≤10h
    Temp. &Atmosphere UniformityCoercivity deviation ≤ ±0.3KA/m, Magnetic saturation deviation ≤ ±0.2%, Temperature variation ≤ ±7 ℃
    Cooling water Temp.≤ 30 ℃
    Cooling water flow rate600L/min
    Power Supply3*AC380V ±10% +N+PE/ 50HZ
    Control cabinet Power SupplySingle-phase, AC210V-250V/50HZ
    Heating power80KVA/240KVA/260KVA/300KVA / 320KVA/380KVA/430KVA
    Temp. Measurement ModeWRE5-26 Dual-core or Single- core thermocouple, mutually redundant, stable and reliable.
    Temp. control modeSingle-zone Temp.Control,3-zone temp. control or 4-zone temp. control
    FunctionsVacuum heating, vacuum dewaxing, H2 dewaxing, heating flowing gas, heating with gas mixture (CO2,CH4,H2), heating pressure gas, Rapid cooling.
    Furnace weight≈8ton/ ≈10ton/≈10ton/≈17ton/ ≈22ton/ ≈23ton/≈23ton/≈30ton
    Input gas allowedAr, H2, N2, CH4
